Overview
The Gigabit PoE Splitter consisting of one PoE Input Port, one Ethernet port, and one DC Power Output port. It fully complies with IEEE802.3 af/at standard, and can work with all IEEE802.3 af/at PoE compliant PSE (Power Sourcing Equipment) or PoE Supplier Adapter. It supports Mode A (end-span) and Mode B (mid-span). The maximum power available at PD is up to 30W and it delivers power up to 100 meters. It features optional 5VDC,9VDC,12VDC,18VDC power supply.
Features
- Complies with IEEE802.3af/at, Maximum power output up to 30W.
- Support 10/100/1000mbps
- Splits the 48VDC power over RJ45 Ethernet cable into different DC output.
- Support wide input voltage range 36V to 57V DC
- Adjustable output 5VDC,9VDC,12VDC,18VDC.
- LED indicators for power input indication.
- Thermal cut off.
- Short circuit protection.
- High efficiency DC/DC converter.
- Plug-and-Play.
